MemoryEngine 1.1.1

MemoryEngine

MemoryEngine is a lightweight, external C# library built to simplify game memory manipulation and 3D-to-2D screen projection for ESP (Extra Sensory Perception) overlays. It is designed for educational purposes in the field of reverse engineering and game engine architecture.

Features

• External Memory Access: Read integers, floats, and pointers from target process memory without the need for DLL injection.
• Module Support: Automatically calculate base addresses to handle dynamic memory allocation.
• Universal ViewMatrix: A highly configurable projection engine that translates 3D game coordinates to 2D screen pixels for any game engine.
• Zero Dependencies: Pure C# implementation using System.Diagnostics and System.Numerics.

Core Classes

1. Engine Class

Handles the communication with the target process.

• ReadMemory(IntPtr address, int size): Reads raw bytes from memory.
• ReadPointer(IntPtr address): Follows a memory address to retrieve a base pointer.
• ReadFloat(IntPtr address) / ReadInt(IntPtr address): Convenience wrappers for data types.

2. ViewMatrix Class

Handles the linear algebra required for ESP.

• ViewMatrix.FromBytes(...): Converts raw memory bytes into a structured 4x4 matrix.
• WorldToScreen(...): Projects 3D world coordinates into 2D overlay coordinates.

Usage Example

using MemoryEngine;
using System.Numerics;

// 1. Initialize the Engine
Engine engine = new Engine("game_process_name", force32Bit: true);

// 2. Configure Projection Settings (Universal across engines)
MatrixSettings settings = new MatrixSettings {
    IsColumnMajor = false,
    IsZeroToOneRange = false,
    InvertY = true
};

// 3. Main Loop Logic
void Update()
{
    // Fetch Matrix and Entity List
    byte[] mBytes = engine.ReadMemory((IntPtr)0x501AE8, 64);
    ViewMatrix matrix = ViewMatrix.FromBytes(mBytes, settings);

    IntPtr entityList = engine.ReadPointer(engine.ModuleBase + 0x10F4F8);
    int numEntities = engine.ReadInt(engine.ModuleBase + 0x10F500);

    for (int i = 0; i < numEntities; i++)
    {
        IntPtr entity = engine.ReadPointer(entityList + (i * 4));

        // Read coordinates
        float x = engine.ReadFloat(entity + 0x34);
        float y = engine.ReadFloat(entity + 0x38);
        float z = engine.ReadFloat(entity + 0x3C);

        // Project to screen
        if (matrix.WorldToScreen(new Vector3(x, y, z), out Vector2 screenPos, width, height))
        {
            // Draw your ESP element here
            DrawBox(screenPos);
        }
    }
}
